JW1390-M7-S

CO2 Laser Cutting Machine

1390M6 with up and down table is a professional co2 laser engraving and cutting machine. The working area is 1300*900mm, Z axis height can be 300mm. Engraving speed is fast. Up to 1200mm/sec. The structure is very strong, which makes it more steady. This machine equipped with a honeycomb and a blade worktable and with a water chiller, makes it possible to install a 100W or even 300W laser tube. The front and back material pass-through door makes it possible to cut long materials.

Inquire Now Next Product Download Price List

Features

CO2 lasers have very high conversion efficiency and are widely used in light industry. It is clean, safe and pollution-free.

The front and back material pass-through door makes it possible to cut long materials.

Whole machine is equipped with leakage overload protector

Independent laser power supply to avoid high voltage interference

Filament optical frame, the light path is more stable

Parameters

Description	JW1390-S
Working Area	1300*900 mm
Working Voltage	AC 220V±10%，50HZ
Control System	Ruida controller
Driver	Leadshine stepper motor, Servo motor
Machine table	Blade table, Honeycomb table (Optional)
Laser type	Glass Inner Cavity Sealed CO2 Laser Wavelength 10.6μm
Energy regulation	Pure circulating water cooling
energy regulation	0-100% stepless control, 0-100% adjustable within the software
Minimum Formed Words	≤±0.05mm
Engraving speed	0 -1200mm/s
Cutting speed	0 - 600mm/s
Minimum Formed Words	English word 1mm
Working environment	Temperature: 0-45C, Humidity 5-95%(No Condensate Water)
Total power	＜3KW
Graphic format supported	BMP, JGP, PNG, DXF, etc.
